As a progression from the DBX series neo midrange driver, we developed the Street series, with an increased magnet structure and larger voice coil Street series have an increased power capability while still remaining lightweight and with a nice feature of spring loaded terminals for easy wiring installation.

By using high grade Neodymium magnets, Copper voice coils and precision engineered soft parts we are able to produce high volume wideband response with real clarity and accuracy.

If high performance and weight saving is what you need the Street series neo midranges are the perfect product for you.

Features

• Neodymium magnets
• Non pressed paper cone
• Dual roll foam surround
• Poly cotton spiders
• Spring loaded terminal

Specification

• Type: Pro Audio Midrange
• Configuration: 1 way
• Speaker Size: 5.25" (130mm)
• RMS Power: 130 watts
• Peak Power: 260 watts
• Sensitivity: 93dB
• Frequency Response: 150Hz - 11kHz
• Impedance: 4 Ohms
• Recommended Amplifier: EDA350.2-E7

Installation

• Mounting Depth: 2.3" (59mm)
• Mounting Diameter: 4.8" (121mm)
